AIMS 3000 W Pure Sine Inverter Charger (12 V → 120 VAC) – 30A / 50A Bypass, UL-458 ETL Certified
$1,173.00
Ordered After you place the order, we will need 1-3 days to prepare the shipment
Order Ready Orders will start to be shipped
Delivered Estimated arrival date range: Sep 27 - Sep 30
Aims Power 3000 WT Inverter Charger 120VAC 50A Bypass 120Vac & 240Vac PICOGLF3K12050BY
Product Description
The ETL listed to UL 458 standards AIMS 3000 watt pure sine inverter charger has surpassed the ETL requirements and includes a 2 year warranty. This inverter is a a combination of an inverter, battery charger and AC auto-transfer switch into one complete system with a peak DC and AC conversion efficiency of 92%. It is unique as the inverter will bypass 50 amps 120V or 240V and outputs 120, ideal for RVs, work trucks, food trucks and boats. It is packed with unique features and it is one of the most advanced inverter chargers on the market today. This inverter also features power factor corrected, sophisticated multi-stage charging and pure sine wave output with unprecedentedly high surge capability to meet demanding power needs of inductive loads without endangering the equipment.
The powerful battery charger is capable of 12 volts at 100 amps, and with power factor corrected, it uses 20-30% less energy from AC input than a standard charger, avoiding nuisance breaker trips or generator overloads. In response to the increasing demand of more advance battery charging, this model is equipped with Battery Temperature Sensing for increased charging precision. The overloads capacity is 300% of continuous output for up to 20 seconds to reliably support tools and equipment longer.
The transformers have been consistently improved for years to achieve the best balance of conversion efficiency, idle consumption and minimum THD. The idle consumption of the line is ultra-low, roughly 1.5% of its rated power. The AC battery priority switch and auto generator start functionally making it ideal to work in either backup power or renewable energy applications.
In AC priority mode, when utility AC power cuts off, the transfer relay is de-energized and the load is automatically transferred to the inverter output. Once the qualified AC utility is restored, the relay is energized and the load is automatically transferred to AC utility.
When customized to battery priority mode via the DIP switch, the inverter will extract power from external power sources in renewable energy systems and a minimal cycle of the battery will be required. With the availability of the auto generator start, an electrical generator can be integrated into the system as a backup and started when the battery voltage goes low.l
Features
- Listed to UL 458 Standards
- Bypasses 50 amps 120V or 240V and outputs 120V
- 2 year warranty
- 3000 watt low frequency inverter
- 9000 watt surge for 20 seconds -3x surge capability
- Battery priority selector
- AC direct connect terminal block
- GFCI – 20 amps
- Marine coated and protected
- Multi stage smart charger 100 amps
- Remote panel available
- Auto gen start
- Auto frequency
- 10msec typical transfer time
- 7 battery type settings for charger including lithium
Specifications
| OUTPUT | |
| Continuous Output Power | 3000 Watts / 3KW |
| Surge Rating (20 secs) | 9000 Watts / 9KW |
| Starting Electric Motor (HP) | 3 HP |
| Output Waveform | Pure Sine |
| Nominal Efficiency | >92% (Peak) |
| Line Mode Efficiency | >95% |
| Power Factor | .9 – 1 |
| Nominal Output Voltage (rms) | 120Vac |
| Output Voltage Regulation | ± 10% RMS |
| Output Frequency | 50/60 Hz ±0.3Hz |
| Short Circuit Protection |
YES. Current Limit Function (fault after 1 sec)
|
| Typical Transfer Time | 10ms (MAX) |
| Max THD @ Full Linear Load | <20% |
| DC INPUT | |
| Nominal Input Voltage | 12 Vdc |
| Minimum Start Voltage | 10Vdc |
| Low Battery Alarm | 10.5Vdc / 11.Vdc |
| Low Battery Trip | 10Vdc / 10.5Vdc |
| High Voltage Alarm & Fault | 16Vdc |
| High DC Input Recovery | 15.5Vdc |
| Low Battery Voltage Recover | 13Vdc |
| Sleep Mode Threshold | >50 Watts (Power Saven On) |
| Input Voltage Range | Narrow: 100-135Vac Wide: 90-135Vac |
| Input Frequency Range |
Narrow: 47-55 ±0.3Hz @ 50Hz, 57-65 ±0.3Hz @ 60Hz
|
| Output Voltage | Depends on battery type |
| Charge | |
| Charger Breaker Rating (120 Vac) | 30A |
| Max Charge Rate | 100A |
| Over Charge Protection Shutdown | 15.7V |
| Battery Type | Fast Vdc Float Vdc |
| Gel USA | 14 13.7 |
| AGM 1 | 14.1 13.4 |
| AGM 2 | 14.6 13.7 |
| Sealed Lead Acid | 14.4 13.6 |
| Gel Euro | 14.4 13.8 |
| Open Lead Acid | 14.8 13.3 |
| Lithium |
14.4 (NOTE: INVERTER MAY SAY CALCIUM BUT CHARGING ALGORITHM BUILT INTO THE INVERTER IS FOR LITHIUM)
|
| De-sulphation | 15.5 for 4 hours |
| Battery Temp Sensor | YES. Part # PICGLFBATS |
| BYPASS & PROTECTION | |
| Input Voltage Waveform | Pure sine from grid or generator |
| Nominal Votage | 120Vac |
| Low Voltage Trip | 80V/100V ±4% |
| Low Voltage Re-engage | 90V/100V ±4% |
| High Voltage Trip | 140V ±4% |
| High Voltage Re-engage | 135V ±4% |
| Max Input AC Voltage | 150Vac |
| Nominal Input Frequency | 50Hz or 60Hz (auto detect) |
| Low Freq Trip |
Narrow: 47 ±0.3Hz @ 50Hz, 57 ±0.3Hz @ 60Hz Wide: 40 ±0.3Hz for 50/60Hz
|
| Low Freq Re-engage |
Narrow: 48 ±0.3Hz @ 50Hz, 58 ±0.3Hz @ 60Hz Wide: 45 ±0.3Hz for 50/60Hz
|
| High Freq Trip |
Narrow: 55 ±0.3Hz @ 50Hz, 65 ±0.3Hz @ 60Hz Wide: No limit for 50/60Hz
|
| High Freq Re-engage |
Narrow: 54 ±0.3Hz @ 50Hz, 64 ±0.3Hz @ 60Hz Wide: No limit for 50/60Hz
|
| Output Short Cirucit Protection | Circuit Breaker |
| Bypass Breaker Rating (120 Vac) | 50A |
| Bypass Breaker Rating (240 Vac) | 50A |
| GFCI Rating | 20A |
| Mounting | Predrilled holes for wall/ground |
| Dimensions | 16.25″L x 11″W x 7″H |
| Weight | 59 lb |
| Shipping Dimensions | 21″H x 14″W x 12″H |
| Shipping Weight | 64 lb |
| Displays | Status LEDs/Optional LCD Remote |
| Warranty | 2 Year |
